| Element | Unit | IS 1786:2008(max) | S.S.Industries (max) |
|---|---|---|---|
| Carbon | % | 0.25 | 0.25 |
| Sulphur | % | 0.040 | 0.035 |
| Phosphorus | % | 0.040 | 0.035 |
| S + P | % | 0.075 | 0.070 |
| Section in mm | ISI Standard Nominal Weight Kg./Mtr. | S.S.Industries Nominal Weight in Kg./Mtr. | Tolerance Limit as per ISI in Kg./Mtr. | S.S.Industries Tolerance Limit in Kg./Mtr. | No. of Pieces Per Bundle 40 Ft |
|---|---|---|---|---|---|
| 8 | 0.395 | 0.375 | 0.367-0.423 | 0.370-0.385 | 15 |
| 10 | 0.617 | 0.580 | 0.574-0.660 | 0.575-0.590 | 10 |
| 12 | 0.888 | 0.850 | 0.844-0.930 | 0.845-0.860 | 7 |
| 16 | 1.580 | 1.520 | 1.500-1.659 | 1.510-1.535 | 4 |
| 20 | 2.470 | 2.410 | 2.395-2.544 | 2.400-2.425 | 2 |
| 25 | 3.850 | 3.780 | 3.730-3.965 | 3.740-3.795 | 1 |
| 28 | 4.830 | 4.750 | 4.685-4.975 | 4.700-4.800 | 1 |
| 32 | 6.310 | 6.250 | 6.121-6.499 | 6.190-6.300 | 1 |
| 40 | 9.850 | 9.700 | 9.554-10.145 | 9.570-9.800 | 1 |
| Mechanical Properties | Unit | IS 1786:2008(max) | S.S.Industries (max) |
|---|---|---|---|
| Yield Strength | N/mm2 | 500 min | 540 min |
| Tensite Strength | N/mm2 | 10% more than YS vut not less than 565 | 10% more than YS vut not less than 620 |
| Elongation | % | 16 min | 18 min |
